Ford Econoline Wagon Details - Prices, Photos, Videos, Features, Rebates & Incentives



2011 Ford Econoline Wagon E-150 XL

E-150 XL

Change Trim

Price Info

Price with options: $28,305

MSRP: $28,305

Base Invoice: $26,129

Body Style

Full-size Passenger Van

MPG

City: 12 - Hwy: 15

Select an image to view:
Ford Econoline Wagon E-150 XL

Choose Your Ford Econoline Wagon E-150 XL Options

Price With Options »

$28,305

2013 Ford Econoline Wagon Pros

Ahead of its replacement by the Transit in 2014, Ford's work-horse passenger van carries into 2013 with no changes.

2013 Ford Econoline Wagon Model Highlights

E-Series vans are available in several regular and "heavy-duty" configurations: E-150 and E-350. The E-350 trim is available in an extended-wheelbase variation.

On the E-150 trims, a 4.6L V8 engine that makes 225 horsepower and 286 pound-feet of torque is standard. A 255-horse 5.4L V8 engine is optional. That same 5.4L is standard on the E-350, while a 6.8L Triton V10 engine capable of 305 horsepower and 420 pound-feet of torque is optional. Standard transmission on the 4.6L and 5.4L models is a 4-speed automatic. A TorqShift 5-speed automatic with overdrive is optional with the 5.4L and standard on V10-equipped vans.

The E-150 has an overall length of 216.7 inches, and extended versions are about 20 inches longer. When properly equipped, the passenger wagon E-350 can hold up to 15 passengers.

Standard safety features include driver and front passenger air bags, 4-wheel anti-lock brake system, tire pressure monitoring system, side-intrusion door beams and AdvanceTrac and Roll Stability. Available safety options include Integrated Trailer Brake Controller, which allows for direct operation of the trailer's electronic brakes, a dash-mounted front-passenger air bag cutoff switch and a rear-view camera system.

Storage space abounds in all E-Series trims, including door panels with integrated second-bin compartments, a contents-retention strap driver's door, a storage tray above the passenger airbag, three large cup holders, an integrated clipboard holder, space for a laptop and a large glove box with a second power point.

Available options on the E-Series include remote keyless entry, exterior upgrade packages, the usual power accessories, carpeted floor covering and insulation and comfort items. Four after-market-configurable dashboard switches are available for accessory integration.

Ford also offers some innovative fleet and job-site technology. Ford's "Crew Chief" is a fleet telematics and diagnostics system that allows small fleet owners to manage their vehicles, track dispatches and keep detailed vehicle maintenance records. Rear air conditioning and a back-up camera system are also available.

2013 Ford Econoline Wagon Model News

Ford's full-size E-Series vehicles have long been the top-selling vans in the U.S. Introduced in 1961, Ford has used the last 50 years to refine their full-size van to perfect it for the contractors and airport shuttles, with whom it is popular. All E-Series are capable of E85 flex fuel. When properly configured, the van can hold up to fifteen adults.

2013 Ford Econoline Wagon Value Writeup

Towing and hauling ability; sturdy truck underpinnings; wide range of interior configurations; advanced fleet and tool management technology

Brakes
Brake ABS System Four Wheel
Brake ABS System (Second Line)
Brake Type Pwr
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Drum - Rear (Yes or )
Front Brake Rotor Diam x Thickness (in) 13.58 x 0.5
Rear Brake Rotor Diam x Thickness (in) 13.58 x 0.35
Rear Drum Diam x Width (in)
Cooling System
Total Cooling System Capacity (qts) 28.3
Electrical
Cold Cranking Amps @ 0? F (2nd) - TBD -
Cold Cranking Amps @ 0? F (Primary) 650
Maximum Alternator Capacity (amps) 225
Maximum Alternator Watts 2635
Engine
Displacement 5.4L/330
Engine Oil Cooler Yes
Engine Order Code 99W
Engine Type Gas V10
Fuel System SMPI
SAE Net Horsepower @ RPM 255 @ 4500
SAE Net Torque @ RPM 350 @ 2500
Mileage
EPA Fuel Economy Est - City (MPG) 13
EPA Fuel Economy Est - Hwy (MPG) 15
Fuel Economy Est-Combined (N/A) 14
Suspension
Axle Capacity - Front (lbs) 5000
Axle Capacity - Rear (lbs) 5520
Axle Ratio (:1) - Front
Axle Ratio (:1) - Rear 4.10
Axle Type - Front Twin I-Beam
Axle Type - Rear Semi-Floating
Shock Absorber Diameter - Front (mm) 35.0
Shock Absorber Diameter - Rear (mm) 35.0
Spring Capacity - Front (lbs) 3700
Spring Capacity - Rear (lbs) 5120
Stabilizer Bar Diameter - Front (in) 1.00
Stabilizer Bar Diameter - Rear (in)
Suspension Type - Front Coil Spring
Suspension Type - Rear 2-Stage Multi-Leaf
Transmission
Clutch Size (in)
Drivetrain Rear Wheel Drive
Fifth Gear Ratio (:1) 0.71
First Gear Ratio (:1) 3.11
Fourth Gear Ratio (:1) 1.00
Reverse Ratio (:1) 2.88
Second Gear Ratio (:1) 2.11
Sixth Gear Ratio (:1)
Third Gear Ratio (:1) 1.55
Trans Description Cont. Automatic w/OD
Trans Description Cont. Again
Trans Order Code 44T
Trans Power Take Off
Trans PTO Access
Trans Type 5
Transfer Case Gear Ratio (:1), High
Transfer Case Gear Ratio (:1), Low
Transfer Case Model
Transfer Case Power Take Off
Vehicle
Rear Door Type Panel
Weight Information
Curb Weight - Front (lbs) 2941
Curb Weight - Rear (lbs) 2350
Gross Axle Wt Rating - Front (lbs) 3700
Gross Axle Wt Rating - Rear (lbs) 5120
Gross Combined Wt Rating (lbs) 13000
Gross Vehicle Weight Rating Cap (lbs) 8600
ENTERTAINMENT
AM/FM stereo -inc: digital clock, (6) speakers
EXTERIOR
16" x 7" styled steel wheels w/sport wheel covers
50/50 hinged swing-out rear cargo door w/172-degree door checks
60/40 hinged side cargo door
Aerotype manual mirrors w/spotters & RH convex lens
Black painted front bumper w/lower black plastic valence
Black painted rear bumper
Interval windshield wipers
LT225/75R16E all-season BSW tires
Sealed beam headlights
Solar tinted glass
Spare tire and wheel
Sport wheel covers
INTERIOR
(2) 3-passenger rear bench seats
(4) 12-volt pwr points-inc: (2) instrument panel, (1) glove box, (1) located rear of driver
8-passenger seating
Black cowl side trim panels
Black plastic stepwell pads
Courtesy light switches for all doors
Dual A-pillar grab handles
Front air conditioning
Front dome light
Front inboard armrest
Front vinyl bucket seats
Front vinyl floor covering
Medium flint cloth/vinyl sunvisors
Medium flint coat hooks
Medium flint full-length acoustical cloth headliner
Medium flint instrument panel w/tachometer
Medium flint plastic front door trim panels
Medium flint polypropylene side/rear quarter door trim panels
Rear cargo light
Rear vinyl floor covering
Slim line color-keyed engine cover console-inc: dual bin stowage, (3) cup holders
Tilt steering wheel
MECHANICAL
120 amp alternator
4-speed automatic transmission w/OD
4.6L EFI FFV V8 engine
5000# capacity twin I-beam front/5520# capacity semi-floating rear axles
650 CCA (72 amp-hr) maintenance-free battery
Electronic throttle control
Front & rear HD shock absorbers
Front stabilizer bar
Pwr 4-wheel disc brakes
Pwr steering
Rear-wheel drive
SAFETY
4-wheel anti-lock braking system (ABS)
AdvanceTrac w/roll stability control
Driver & front passenger 2nd generation airbags
Dual note electric horn
Front height adjustable 3-point safety belts
Rear 3-point shoulder/lap safety belts in all positions
Tire pressure monitoring system (TPMS)
WARRANTY
Basic Warranty: 3 Years, 36,000 Miles.
Corrosion Warranty: 5 Years, Unlimited Miles.
Drive Train Warranty: 5 Years, 60,000 Miles.
Roadside Assistance: 5 Years, 60,000 Miles.
