Ford Super Duty F-450 DRW Details - Prices, Photos, Videos, Features, Rebates & Incentives



2012 Ford Super Duty F-450 DRW 4WD Crew Cab 172" XL

4WD Crew Cab 172" XL

Change Trim

Price Info

Price with options: $49,395

MSRP: $49,395

Base Invoice: $45,486

Body Style

Crew Cab Pickup - Long Bed

MPG

City: 0 - Hwy: 0

Select an image to view:
Ford Super Duty F-450 DRW 4WD Crew Cab 172" XL

Choose Your Ford Super Duty F-450 DRW 4WD Crew Cab 172" XL Options

Price With Options »

$49,395

2013 Ford Super Duty F-450 DRW Pros

Ford's commercial-oriented Super-Duty trucks return for 2013 with plenty of small changes. Among them is an improved braking system, including a larger parking brake and bigger front and rear brake rotors. The gross vehicle weight rating has increased to a class-leading 14,000 pounds. Other changes include the addition of a new Platinum series model, which features a perforated mesh grille with satin chrome surround and other exterior touches, while inside you'll find premium wood grain surfaces, a heated leather steering wheel and more.

Ford's exclusive SYNC with MyFord Touch is new for 2013. It's standard on Lariat, King Ranch and Platinum models. The system includes an 8-inch high-resolution touchscreen display, with access to climate controls, phone, entertainment, and navigation features, along with voice control. The display also shows view from the rear backup camera.

New exterior colors include Blue Jeans Metallic, Kodiak Brown Metallic and Ruby Red Metallic.

2013 Ford Super Duty F-450 DRW Model Highlights

The 2013 Ford Super Duty trucks are offered in F-250, F-350 and F-450 models, designating progressively higher tow and weight ratings. Compared to light-duty, full-size trucks, like the F-150, the Super Duty models have a stronger structure, along with heavy-duty components throughout and a powertrain lineup chosen for sheer pulling and hauling ability.

Ford Super Duty trim levels include XL, XLT, Lariat, King Ranch and Platinum. Throughout the lineup, there's a choice of two different engines -- either a 385-horsepower, 6.2L gasoline V8, or a 400-horsepower, 6.7L Power Stroke diesel engine. The gasoline engine is also compatible with E85 (85 percent ethanol) and can be equipped for propane or compressed natural gas (CNG), which might make it attractive for fleet use. However, in any sort of practical use, the diesel engine, with its mammoth 800 pound-feet of torque, comes out far ahead of the gas engine's 405 pound-feet. No matter which engine, the Super Duty trucks come with a heavy-duty 6-speed SelectShift automatic transmission.

F-350 and F-450 models get a reinforced frame and hitch system compared to F-250 models. Both the F-350 and F-450 are also offered in a dual-rear-wheel (DRW) configuration for better stability with heavy loads. Models with a conventional bumper hitch can tow up to 17,500 pounds, while those that upgrade to a fifth-wheel hitch can manage up to 24,500 pounds.

All single-rear-wheel models of the Super Duty trucks come with electronic stability control plus trailer sway control and hill start assist to help with standing starts on steep uphill slopes. Anti-lock brakes are also included and an integrated trailer brake controller is available. Integrated exhaust braking -- like that of big rigs -- is on the options list with the diesel, while Hill Descent Control also helps on slippery downhills, even when towing. Big PowerScope trailer-tow mirrors are also available. Heavy-duty buyers no longer need to forgo additional airbags -- side seat airbags and side-curtain bags with a roll sensor are included.

Ford's SYNC with MyFord Touch in-dash multimedia system is standard on Lariat, King Ranch, and Platinum models. It features an 8-inch high-resolution touchscreen display, with access to climate controls, phone, entertainment, and navigation features, along with voice control. The display also shows view from the rear backup camera.

The options list for the F-Series Super Duty Trucks isn't as comfort-and-luxury-oriented as that of the F-150, though trucks at the top of the range can be ordered as luxuriously as you please. Some innovative specialized features, such as a Ford Work Solutions Crew Chief system for fleets and a Cable Lock security system for equipment, are geared toward those who use the Super Duty for serious work, like at a construction site.

2013 Ford Super Duty F-450 DRW Model News

The F-Series Super Duty trucks bear a resemblance to the ubiquitous, best-selling F-150 pickups. These Super Duty models are made to serve an especially pure purpose -- to reliably, safely and confidently haul heavy loads or heavy trailers, day after day. What's surprising is that these workhorses are actually quite comfortable -- and almost luxurious -- inside.

Ford boasts that their PowerStroke diesel engine is the most powerful diesel pickup engine on the market and that the Super Duty F-350 DRW (dual rear wheel) model has a best-in-class payload (7,110 pounds) and fifth-wheel tow rating (22,700), as well as a best-in-class conventional tow rating of 17,500 pounds.

2013 Ford Super Duty F-450 DRW Value Writeup

Flexibility for commercial use; tougher than standard full-size trucks; class-leading tow ratings; Power Stroke diesel's 800 pound-feet of torque; full roster of safety features

Brakes
Brake ABS System 4-Wheel
Brake ABS System (Second Line)
Brake Type Pwr
Disc - Front (Yes or ) Yes
Disc - Rear (Yes or ) Yes
Drum - Rear (Yes or )
Front Brake Rotor Diam x Thickness (in) 14.5 x 0.6
Rear Brake Rotor Diam x Thickness (in) 15.4 x 0.5
Rear Drum Diam x Width (in)
Cooling System
Total Cooling System Capacity (qts) 38.9
Electrical
Cold Cranking Amps @ 0? F (2nd) 750
Cold Cranking Amps @ 0? F (Primary) 750
Maximum Alternator Capacity (amps) 357
Maximum Alternator Watts 2100
Engine
Displacement 6.7L/406
Engine Oil Cooler Yes
Engine Order Code 99T
Engine Type Turbocharged Diesel V8
Fuel System Direct Injection
SAE Net Horsepower @ RPM 400 @ 2800
SAE Net Torque @ RPM 800@ 1600
Mileage
EPA Fuel Economy Est - City (MPG)
EPA Fuel Economy Est - Hwy (MPG)
Fuel Economy Est-Combined (N/A)
Suspension
Axle Capacity - Front (lbs) 6000
Axle Capacity - Rear (lbs) 9500
Axle Ratio (:1) - Front 4.30
Axle Ratio (:1) - Rear 4.30
Axle Type - Front Dana Super 60 Monobeam
Axle Type - Rear Full-Floating
Shock Absorber Diameter - Front (mm) 35
Shock Absorber Diameter - Rear (mm) 35
Spring Capacity - Front (lbs) 6000
Spring Capacity - Rear (lbs) 9000
Stabilizer Bar Diameter - Front (in) 1.26
Stabilizer Bar Diameter - Rear (in) 0.87
Suspension Type - Front Coil
Suspension Type - Rear Leaf Spring
Transmission
Clutch Size (in)
Drivetrain Four Wheel Drive
Fifth Gear Ratio (:1) 0.85
First Gear Ratio (:1) 3.97
Fourth Gear Ratio (:1) 1.14
Reverse Ratio (:1) 3.12
Second Gear Ratio (:1) 2.31
Sixth Gear Ratio (:1) 0.67
Third Gear Ratio (:1) 1.51
Trans Description Cont. Automatic w/manual shift
Trans Description Cont. Again
Trans Order Code 44W
Trans Power Take Off Yes
Trans PTO Access LH Side
Trans Type 6
Transfer Case Gear Ratio (:1), High 1.00
Transfer Case Gear Ratio (:1), Low 2.72
Transfer Case Model New Venture 273
Transfer Case Power Take Off
Weight Information
Curb Weight - Front (lbs) 4767
Curb Weight - Rear (lbs) 3411
Gross Axle Wt Rating - Front (lbs) 6000
Gross Axle Wt Rating - Rear (lbs) 9000
Gross Combined Wt Rating (lbs) 33000
Gross Vehicle Weight Rating Cap (lbs) 13300
ENTERTAINMENT
AM/FM stereo -inc: clock, (2) speakers
EXTERIOR
(7) LT245/75R17E all-season BSW tires
17" forged polished aluminum wheels -inc: bright chrome hub covers & center ornaments
6" angular molded black step bars
Black door handles
Black molded-in-color grille
Black painted rear bumper
Black painted steel front bumper w/grained molded-in-color top cover & black lower air dam
Box-rail & tailgate top-edge moldings
Dual beam jewel-effect headlamps
Front fender vents
Front/rear license plate brackets
Full-size spare tire w/lock & carrier
Manual telescoping trailer tow mirrors w/manual glass
Pickup box/cargo lights
Removable locking tailgate w/black handle & TailGate Assist
Roof clearance lights
Solar tinted glass
Underhood service light
Variable intermittent windshield wipers
INTERIOR
(2) aux pwr outlets in instrument panel
(4) air registers w/positive shut-off
3-blink lane change signal
Air conditioning
Black vinyl full-floor covering
Color-keyed cloth headliner
Color-keyed molded door trim panel -inc: hard armrest, grab handle, reflector
Color-keyed scuff plates
Dash-top tray
Driver & front passenger grab handles
Driver manual lumbar support
Dual color-keyed coat hooks
Dual color-keyed vinyl sunvisors-inc: driver-side pocket, passenger-side mirror insert
Front door operated dome lamp w/time delay off & IP switch
Front passenger-side roof ride handle
Front/rear map lamps
Glove box
HD vinyl 40/20/40 split bench front seat -inc: center armrest, cupholder, storage
Instrument panel mounted storage
Intelligent oil life minder
Multifunction switch message center -inc: ice blue lighting, 3-button message control on steering wheel, outside temp display
Overhead console -inc: storage bins for garage door opener & sunglasses
Rear seating roof ride handles
SecuriLock anti-theft ignition
Tilt/telescoping steering column
Vinyl 60/40 flip-up/fold-down rear split bench seat -inc: (3) head restraints
MECHANICAL
(2) front tow hooks
157-amp HD alternator
17.5K trailer hitch receiver -inc: 2.5" hitch & 2" sleeve reducer
4-ton hydraulic jack
4-wheel drive
4.30 axle ratio w/limited slip rear axle
6.7L 32-valve Pwr Stroke V8 diesel engine
78 amp/hr (750 CCA) dual batteries
8' pickup box -inc: (4) tie-down hooks, partitionable & stackable storage
Front stabilizer bar
HD gas shock absorbers
Manual transfer case & hubs
Mono-beam wide track front suspension w/extended axle
Pwr steering w/steering damper
Stationary elevated engine idle control (SEIC)
TorqShift 6-speed automatic transmission w/tow/haul mode
Trailer brake controller *Compatible w/select electric over hydraulic brakes*
Trailer tow pkg -inc: 7-wire harness w/relays, 7/4 pin combination connector
SAFETY
BeltMinder seatbelt-not-buckled chime & flashing warning light
Child seat tethers on all rear passenger seats
Color-keyed safety belts w/front seat outboard height adjustable D-rings
Driver & front passenger airbags
Driver & front passenger side airbag/curtain
Engine-only traction control (EOTC)
Front center seat integrated restraints (SIR)
Hill start assist control
MyKey system -inc: top speed limiter, audio volume limiter, early low fuel warning, programmable sound chimes, BeltMinder w/audio mute
Pwr 4-wheel disc anti-lock braking system (ABS)
Rear door child safety locks
Safety Canopy system
SOS post crash alert system
Trailer sway control
WARRANTY
Basic Warranty: 3 Years, 36,000 Miles.
Corrosion Warranty: 5 Years, Unlimited Miles.
Drive Train Warranty: 5 Years, 60,000 Miles.
Roadside Assistance: 5 Years, 60,000 Miles.
